EMC Compliance:The operating table has passed EMC electromagnetic compatibility tests to ensure that internal information systems’ weak circuits are not interfered with by electromagnetic signals (national-level testing report available).
Adjustable Height: The operating table has a minimum height of 700mm and a maximum height of 1000mm, with a lifting range ≥300mm, ensuring it meets the surgical needs of various specialties, including thoracic, abdominal, gynecological, ENT, urology, and colorectal surgeries.
Modular Design: The table features an advanced modular design, enabling the combination of multiple functions. The tabletop has a length ≥2010mm and width ≥500mm, and the T-shaped base design increases comfort for the surgeon’s feet, making it suitable for all surgical specialties.
Five Independent Sections: The tabletop is divided into five independent sections, enabling accurate and quick positioning for various body positions such as knee-elbow prone, lateral, lithotomy, seating, and supine positions.
Built-In Kidney Bridge: The table is equipped with a built-in kidney bridge, with an elevation range ≥110mm, making it suitable for surgeries like gallbladder and kidney operations.
Leg Board Design: The leg board is designed with a split-leg system, allowing lateral abduction of ≥90° and downward folding of ≥90°. It is detachable, making it easy to clean and disinfect. After detachment, it can be used with orthopedic traction devices for lower limb traction surgeries.
Pneumatic Leg Board Adjustment: The leg board uses imported gas springs for easy adjustment and high stability. (Customs declaration available)
Weight Capacity: The table supports a weight capacity of ≥200kg, accommodating patients of various body sizes during surgery.
Stainless Steel Construction: The lift cover, base cover, guide rails, and accessories are made of stainless steel, providing high mechanical strength and making it easy to clean and disinfect.
Full Table Movement: The entire tabletop can move forward and backward, with a distance of ≥400mm, enabling full-body C-arm imaging without blind spots.
Head and Backrest Adjustment: The headrest can be raised ≥50° and lowered ≥90°, and it is detachable for easy connection with other equipment. The backrest can be raised ≥75° and lowered ≥10°. The tabletop can tilt left-right by ≥20°, forward by ≥25°, and backward by ≥20°.
High Transparency Surface: The tabletop is made from medical-grade high-transparency material, ensuring it can support weight while being suitable for high-definition imaging and intraoperative fluoroscopy.
Memory Foam Mattress: The mattress is made from high-quality memory foam with a thickness of ≥60mm, providing excellent anti-static and pressure-relieving properties, preventing bedsores during long surgeries.
Flame-Resistant Material Compliance: The table’s flammable components meet the CAN/CGSB-155.20-2017 flame-retardant standards. (Certification available)
High-Performance Battery: The table comes with a high-performance rechargeable battery, providing enough power for ≥50 surgeries on a single charge.
Ergonomic Design: The entire table is designed based on ergonomic principles and powered by low-voltage DC motors, ensuring stable performance with low noise. All motors are imported, ensuring high safety and reliability. (Customs declaration available)
Electric Control Functions: The table features electric control for height adjustment, left-right tilt, forward-backward tilt, backrest fold, and full tabletop translation.
Safety Edge Rails: The side rails of the operating table feature an anti-slip design to prevent accessories from sliding off the table. (Certification available)
Foot-Pedal Diagonal Brake System: The table is equipped with a foot-pedal diagonal brake system, with brakes located on one side of the foot. The mechanical design features left-right movable pedals. Once locked, the table’s position remains secure, ensuring stability and safety during surgery.
Silent Castors: The table is equipped with imported silent castors, ensuring minimal movement noise and providing excellent durability and wear resistance.
