EMC Compliance:Passed EMC electromagnetic compatibility tests, ensuring internal information systems are protected from electromagnetic interference (national-level testing report available).
High Transparency Surface:The tabletop is made of medical-grade high-transparency materials, ensuring weight support while being suitable for high-definition imaging and intraoperative fluoroscopy.
Advanced Mechanical Drive Structure:Features precision mechanical transmission with non-electric push rods and electric hydraulics, replacing traditional electric push rods and hydraulic systems. No risk of thrust limitations or oil leakage, offering superior rigidity, smooth and uniform operation, accurate positioning, and durability.
Large Travel Range for X-ray Imaging:The table allows for a 300±20mm electric horizontal movement, enabling full suspension of the patient’s lower legs without needing to switch head/leg boards. It provides precise and convenient positioning space for C-arm imaging and full-body X-ray fluoroscopy. High-precision linear guides ensure smooth table operation. (Certification available)
Adjustable Height:The bed’s lowest height is 700±20mm, and the highest is 1000±20mm, with a 300mm lifting range, ensuring versatility for various imaging needs.
Electric Tilt Control:The surgical table can tilt forward and backward by 25°±2° and sideways by 20°±2°. The backboard can be raised 60°±2° and lowered 18°±2°, all powered by electric control.
Leg Board Adjustments:The leg board can be raised 30°±5°, lowered 90°±5°, and externally rotated 90°±5° manually. The leg board is detachable and compatible with orthopedic traction devices.
One-Touch Reset:The table has a one-touch reset feature to simplify post-operation cleanup and sterilization, improving efficiency. (Certification available)
Durable Frame:The bed’s frame is made of high-quality nickel-chromium stainless steel, ensuring rust-free performance for over 15 years. The base cover is constructed from special high-strength materials with anti-glare surface treatment to reduce eye strain for healthcare workers and facilitate cleaning and disinfection.
Memory Foam Mattress:The mattress is made from high-grade memory foam, ≥60mm thick, providing excellent anti-static and pressure-reducing properties to prevent bedsores during long surgeries.
High-Performance Battery:Equipped with a 24V lead-acid rechargeable battery, providing 50-80 operations on a full charge. The battery requires no maintenance and ensures operation even without external power. It is supported by AC power for maximum safety.
Optional Accessories:A non-metallic, full carbon fiber headrest made from carbon fiber materials, offering high-definition fluoroscopic imaging and meeting 3D head imaging requirements.
